GB/T 3091-2015 Standard - Welded Steel Pipes for Low-pressure Fluid Conveyance

 1. Scope

Applies to welded steel pipes for low-pressure fluid transport, typically with a nominal diameter ≤150 mm and wall thickness ≤12.5 mm.

 2. Ordering Information

Buyers should specify in contracts:

- Standard number (GB/T 3091-2015)

- Steel grade (e.g., Q195, Q215A/B, Q235A/B, Q265A/B, Q295A/B, Q345A/B)

- Dimensions (outer diameter, wall thickness, length)

- Surface treatment (galvanized or black)

- Special requirements (e.g., hydrostatic testing, non-destructive testing).

 3. Main Steel Grades & Chemical/Mechanical Properties

 Steel Grades:

- Non-galvanized pipes: Q195, Q215A/B, Q235A/B, Q265A/B, Q295A/B, Q345A/B.

- Galvanized pipes: Typically use Q195–Q345 grades.

 Key Requirements:

- Chemical composition: Limits for C, Mn, Si, S, P, etc., vary by grade.

- Mechanical properties: Tensile strength, yield strength, and elongation comply with grade-specific values (e.g., Q235: yield strength ≥235 MPa).

 4. Manufacturing Process

- Pipes are welded via high-frequency resistance welding (ERW) or other welding methods.

- Galvanized pipes undergo hot-dip galvanizing (zinc coating ≥500 g/m² for DN≥100 mm).

 5. Inspection Requirements

 (1) Dimensional Tolerances:

- Outer diameter, wall thickness, and length must meet specified limits.

 (2) Mechanical Tests:

- Tensile test, flattening test, bending test (for pipes ≤DN50 mm), and hydrostatic test (or non-destructive testing).

 (3) Surface Quality:

- No cracks, laps, or harmful defects. Galvanized pipes must have a continuous, adherent zinc layer.

 (4) Hydrostatic Test:

- Test pressure = 5 MPa (or 2.5 MPa for galvanized pipes); held for ≥5 sec without leakage.

 (5) Non-Destructive Testing (NDT):

- Alternative to hydrostatic testing; methods include eddy current or ultrasonic testing.

 6. Marking & Certification

- Each pipe must be marked with: manufacturer’s name, steel grade, size, standard number, and inspection mark.

- A quality certificate must accompany deliveries, including test results.

 7. Comparison with Previous Versions

GB/T 3091-2015 replaces the 2008 version, with updates to:

- Expanded steel grades (added Q265, Q295, Q345).

- Clarified inspection rules for galvanized pipes.

- Enhanced NDT requirements.

 Key Applications

Widely used in construction, plumbing, firefighting, and low-pressure gas/water supply systems.
