GOST 8732 Seamless Pipes | Hot-Rolled Steel Tubes for Structure Use

GOST 8732 SMLS Structure Pipe

GOST 8732 applies to seamless hot-rolled steel pipes for general engineering and structural purposes, including:
- Pipes for mechanical components
- Structural parts (e.g., frames, supports)
- Pipes for non-critical pressure applications

Request a quote

description

GOST 8732 Seamless Hot-rolled Steel Pipes

1. Scope

GOST 8732 applies to seamless hot-rolled steel pipes for general engineering and structural purposes, including:

- Pipes for mechanical components

- Structural parts (e.g., frames, supports)

- Pipes for non-critical pressure applications

2. Ordering Information

When ordering pipes under GOST 8732, the following must be specified:

- Standard designation (e.g., GOST 8732-202X)

- Dimensions (outer diameter, wall thickness, length)

- Steel grade (e.g., St20, 09G2S, 12Х18Н10Т)

- Delivery condition (hot-rolled, heat-treated if required)

- Additional requirements (e.g., non-destructive testing, special tolerances)

3. Main Steel Grades

The standard includes carbon and alloy steel grades, such as:

| Category | Steel Grades (Examples) |

| Carbon Steels | St10, St20, St35, St45 |

| Low-Alloy Steels| 09G2S, 17G1S, 10Г2 |

| Alloy Steels | 12Х18Н10Т (stainless), 30ХГСА |

Note: Chemical composition and mechanical properties (yield strength, tensile strength, elongation) are specified in referenced standards (e.g., GOST 1050, GOST 4543).

4. Dimensional Tolerances

- Outer diameter: ±1.0–1.5% (varies by size)

- Wall thickness: ±10–12.5%

- Length:

- Unmeasured: +100 mm

- Measured: ±10 mm

5. Inspection & Testing Requirements

Pipes must undergo:

1. Mechanical Tests (tensile, hardness) – sampled per batch.

2. Hydraulic Pressure Test (optional, if specified).

3. Non-Destructive Testing (NDT) (ultrasonic or eddy current, if required).

4. Visual & Dimensional Inspection (surface defects, ovality, straightness).

6. Marking & Packaging

- Each pipe is marked with:

- Manufacturer’s name/logo

- Steel grade

- Heat number

- Inspection certificate number

- Packaging: Bundled with protective coatings (anti-rust oil, varnish) or as agreed.

7. Certification

Suppliers must provide a certificate of compliance including:

- Chemical analysis

- Mechanical test results

- Heat treatment data (if applicable)

- NDT reports (if applicable)

Want to order the same ? Contact us Now to send your request.
