GB/T 14976 – Seamless Steel Tubes for Fluid Transportation

1. Scope

- Applies to seamless steel tubes used for conveying fluids (e.g., water, oil, gas).

- Covers hot-rolled (extruded) and cold-drawn (cold-rolled) tubes.

2. Normative References

- References other GB standards for testing, dimensions, and material properties (e.g., GB/T 222, GB/T 223, GB/T 241).

3. Ordering Information

Buyers must specify:

- Steel grade (e.g., 10, 20, 16Mn, 304, 316L).

- Dimensions (outer diameter, wall thickness, length).

- Manufacturing process (hot-rolled/cold-drawn).

- Special requirements (e.g., heat treatment, non-destructive testing).

4. Steel Grades and Chemical Composition

- Common grades include carbon steel (10, 20), low-alloy steel (16Mn), and stainless steel (304, 316L).

- Chemical composition must comply with specified limits (e.g., C, Si, Mn, P, S, Cr, Ni for stainless steels).

5. Manufacturing Process

- Tubes are produced via hot rolling, cold drawing, or cold rolling.

- Heat treatment (annealing, normalizing, or quenching/tempering) is required for certain grades.

6. Technical Requirements

- Dimensions & Tolerances: Must meet GB/T 17395 standards.

- Mechanical Properties: Tensile strength, yield strength, elongation per grade.

- Hydrostatic Test: Mandatory (test pressure calculated per formula).

- Surface Quality: Free from cracks, folds, and severe scratches.

- Non-Destructive Testing (NDT): Ultrasonic or eddy current testing if specified.

7. Inspection and Testing

- Chemical analysis (per GB/T 222/223).

- Mechanical tests (tensile, hardness, flattening, flaring, etc.).

- Hydrostatic/NDT tests.

- Sampling frequency: Batch-wise (e.g., 10% for mechanical tests).

8. Marking and Packaging

- Tubes are marked with steel grade, size, standard number, and manufacturer’s name.

- Packaging: Bundled or crated with rust-proof measures for transport.

9. Certification

- Manufacturer provides a quality certificate including test results and compliance statement.

Key Notes

- Latest Version: Confirm if GB/T 14976-XXXX (replace XXXX with the current year) supersedes older editions.

- Stainless Steel Grades: Added in recent updates (e.g., 304, 316L).

- NDT Emphasis: Enhanced inspection requirements in newer versions.
