ASTM B167/B167M Standard Specification for Nickel-Chromium-Iron Alloys (UNS N06600, N06601, N06603, N06690, N06693, N06025, and N06045) Seamless Pipe and Tube

 1. Scope

This standard covers seamless pipe and tube made of nickel-chromium-iron alloys (e.g., UNS N06600, N06601, N06690) for high-temperature and corrosive service. It includes mechanical properties, dimensions, and testing requirements.

 2. Ordering Information

Buyers must specify:

- ASTM designation (B167 or B167M for metric)

- Alloy UNS number (e.g., N06600)

- Dimensions (OD, wall thickness, length)

- Condition (annealed, cold-worked, etc.)

- Test requirements (if additional to standard)

- Certification (if needed)

- Special packaging (if required)

 3. Material Codes (UNS Alloys)

Common alloys covered:

- N06600 (Ni-Cr-Fe, general-purpose)

- N06601 (Higher temperature resistance)

- N06690 (Improved corrosion resistance)

- Others: N06603, N06693, N06025, N06045.

 4. Chemical Composition

- Limits for Ni, Cr, Fe, C, Mn, Si, Cu, S, and other trace elements are specified for each alloy.

- Material analysis must conform to ASTM E1473 or equivalent.

 5. Mechanical Properties

- Tensile strength, yield strength, elongation requirements vary by alloy and condition (annealed/cold-worked).

  - Example (N06600, annealed):

    - Tensile: ≥80 ksi (550 MPa)

    - Yield: ≥35 ksi (240 MPa)

    - Elongation: ≥30%

 6. Inspection & Testing Requirements

- Chemical analysis (per heat/lot).

- Tensile testing (per lot).

- Hydrostatic or nondestructive testing (e.g., eddy current) for leaks/defects.

- Dimensions and visual inspection (surface defects, straightness).

- Certification: Mill test reports (MTRs) must comply with the standard.

 7. Surface Finish & Dimensions

- Surfaces must be free of scale, cracks, and imperfections.

- Dimensional tolerances for OD, wall thickness, and length are specified.

 8. Certification & Marking

- Marking: ASTM standard, alloy, heat number, size, and manufacturer’s identification.

- Certification: Supplier must provide compliance documentation.

 9. Keywords

Nickel alloys, seamless pipe, corrosion-resistant, high-temperature, UNS N06600, N06690.

 Material Codes (UNS Alloys) in ASTM B167/B167M

1. N06025 (Ni-Cr-Fe-Mo-Cu alloy)

2. N06045 (Ni-Cr-Fe-Si alloy)

3. N06600 (Nickel-Chromium-Iron, general-purpose alloy)

4. N06601 (Nickel-Chromium-Iron, improved high-temperature strength)

5. N06603 (Nickel-Chromium-Iron, oxidation-resistant)

6. N06690 (Nickel-Chromium-Iron, low-carbon, corrosion-resistant)

7. N06693 (Nickel-Chromium-Iron-Aluminum, high-temperature resistant)

 Key Notes:

- N06600 is the most common alloy in this standard, widely used in high-temperature and corrosive environments.

- N06690 is often used in nuclear applications due to its low carbon content.

- N06601 & N06693 offer enhanced oxidation resistance at elevated temperatures.
