ASTM B165/B165M Standard Specification for Nickel-Copper Alloy (UNS N04400) Seamless Pipe and Tube

 1. Scope

- Covers seamless pipe and tube made from nickel-copper alloy UNS N04400 (commonly known as Alloy 400).

- Applicable to general corrosion-resistant and heat-resistant applications, including condensers, heat exchangers, and other high-performance systems.

- Two unit systems:

  - B165: Inch-pound units.

  - B165M: SI units (metric).

 2. Ordering Information

Orders must specify:

- ASTM designation (B165 or B165M) and year of issue.

- Dimensions (outer diameter, wall thickness, length).

- Temper (e.g., annealed, cold-worked).

- Surface finish (e.g., pickled, polished).

- End finish (e.g., plain, beveled).

- Certification/Test Reports (if required).

- Additional testing (e.g., hydrostatic, nondestructive testing).

 3. Material and Chemical Composition

- Alloy UNS N04400:

  - Nickel (Ni): ≥63.0%.

  - Copper (Cu): 28.0–34.0%.

  - Iron (Fe): ≤2.5%.

  - Manganese (Mn): ≤2.0%.

  - Carbon (C): ≤0.3%.

  - Silicon (Si): ≤0.5%.

  - Sulfur (S): ≤0.024%.

- Trace elements limited to avoid detrimental effects.

 4. Mechanical Properties

Requirements vary by temper (annealed vs. cold-worked):

| Property            | Annealed (Typical) | Cold-Worked (Typical) |

| Tensile Strength | ≥70 ksi (485 MPa)  | ≥90 ksi (620 MPa)     |

| Yield Strength  | ≥25 ksi (170 MPa)  | ≥65 ksi (450 MPa)     |

| Elongation      | ≥35%               | ≥15%                  |

 5. Inspection and Testing Requirements

- Chemical Analysis: Performed to verify composition (ASTM E1473 or equivalent).

- Mechanical Testing: Tensile tests per ASTM E8/E8M.

- Hydrostatic Testing: Optional; pressure specified by purchaser.

- Nondestructive Testing (NDT): Eddy current or ultrasonic testing if required.

- Visual Inspection: Surface imperfections must not exceed specified limits.

 6. Certification and Marking

- Certification: Manufacturer must provide a Certificate of Compliance with test results.

- Marking: Each tube/pipe must be marked with:

  - ASTM standard (B165/B165M).

  - Alloy (UNS N04400).

  - Heat number.

  - Size and temper.

  - Manufacturer’s name or trademark.

 7. Keywords

- Nickel-copper alloy, UNS N04400, Alloy 400, seamless pipe, seamless tube, corrosion-resistant, heat-resistant.

The primary material designation in this standard is:

 UNS N04400

Common Names:

  - Alloy 400 (generic industry name)

  - Monel 400 (trade name, originally from Special Metals Corporation)

Werkstoff Number (European): 2.4360

Other Equivalent Standards:

  - EN: NiCu30Fe (EN 2.4360)

  - ISO: NiCu30Fe

  - ASME SB165: Same as ASTM but for ASME Boiler and Pressure Vessel Code applications.

 Key Characteristics of UNS N04400 (Alloy 400)

- Composition:

  - Ni (Nickel): ≥63%

  - Cu (Copper): 28–34%

  - Fe (Iron): ≤2.5%

  - Mn (Manganese): ≤2.0%

  - C (Carbon): ≤0.3%

- Corrosion Resistance: Excellent in seawater, acids, and alkaline environments.

- Applications: Used in marine, chemical processing, heat exchangers, and oil & gas industries.

 Summary of Material Codes

| Standard  | Material Designation | Common Names |

| ASTM B165/B165M | UNS N04400 | Alloy 400, Monel 400 |

| EN (Europe) | 2.4360 | NiCu30Fe |

| ISO | NiCu30Fe | – |

| ASME SB165 | UNS N04400 | Same as ASTM |
