ASTM B407-21 Standard Specification for Nickel-Iron-Chromium Alloy Seamless Pipe and Tube

 1. Scope

- Covers seamless pipe and tube made of nickel-iron-chromium alloys (UNS N08120, N08800, N08810, N08811, N08890, N08140).

- Designed for high-temperature and corrosive service (e.g., heat exchangers, furnace components, chemical processing).

 2. Ordering Information

Buyers must specify:

- ASTM B407-21 and alloy UNS number (e.g., N08800).

- Dimensions (OD, wall thickness, length).

- Condition (hot-finished, cold-worked, annealed).

- Surface finish (e.g., pickled, polished).

- Testing requirements (hydrostatic, NDE, corrosion tests).

- Certification (EN 10204 3.1/3.2 or equivalent).

- Additional requirements (e.g., grain size, special tolerances).

 3. Material Codes (UNS Alloys)

 UNS Alloy Designations in ASTM B407-21

l N08120

   - Common Name: None (proprietary alloy)

   - Key Features: High chromium (25%) and nickel (37%) with niobium (Nb) addition for sulfidation resistance.

l N08800

   - Common Name: Incoloy® 800

   - Key Features: General-purpose alloy with balanced Ni-Fe-Cr composition for oxidation resistance.

l N08810

   - Common Name: Incoloy® 800H

   - Key Features: Higher carbon (0.05–0.10%) than N08800 for improved high-temperature strength.

l N08811

   - Common Name: Incoloy® 800HT

   - Key Features: Controlled Ti/Al (≥0.85%) for superior creep rupture strength.

l N08890

   - Common Name: Incoloy® 800AT

   - Key Features: Low titanium (Ti ≤ 0.03%) for enhanced weldability.

l N08140

   - Common Name: None (specialized alloy)

   - Key Features: Modified Ni-Fe-Cr with improved corrosion resistance in aggressive environments.

 Notes

- N08800, N08810, and N08811 are the most widely used grades, especially in high-temperature applications.

- N08120 and N08140 are niche alloys for extreme corrosion resistance.

 4. Chemical Composition

- Strict elemental limits (e.g., N08800: Ni 30–35%, Cr 19–23%, Fe ≥ 39.5%).

- Impurity control: Low sulfur (≤0.015%) and phosphorus (≤0.025%).

 5. Mechanical Properties

| Alloy | Condition | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |

| N08800 | Annealed | ≥485 | ≥170 | ≥30 |

| N08810 | Annealed | ≥450 | ≥170 | ≥30 |

| N08811 | Annealed | ≥450 | ≥170 | ≥30 |

 6. Heat Treatment

- Solution Annealing: Mandatory for all alloys (e.g., N08800 at 1100–1200°C, rapid cooling).

- Stress Relieving: Optional for cold-worked tubes.

 7. Inspection & Testing Requirements

- Chemical Analysis: Per ASTM E354 (wet) or E1473 (OES).

- Tensile Testing: Per ASTM E8/E8M (one test per lot).

- Hydrostatic Testing: Optional (per ASTM B829).

- NDE: Eddy current (ASTM E426) or ultrasonic (ASTM E213) if specified.

- Corrosion Testing: Optional (e.g., ASTM G28 for intergranular corrosion).

 8. Surface & Dimensional Requirements

- Surface: Free of cracks, scale, or pits; minor scratches allowed.

- Tolerances:

  - OD: ±0.8% for hot-finished, ±0.4% for cold-worked.

  - Wall Thickness: ±10% for pipes, ±5% for tubes.

 9. Certification & Marking

- MTR (Material Test Report): Includes heat analysis, mechanical tests, and compliance.

- Marking: Alloy UNS (e.g., "N08800"), ASTM B407-21, heat number, size, and manufacturer’s logo.

 10. Key Applications

- Heat exchangers, boilers, furnace tubing (N08800/N08810).

- Chemical processing (N08120 for sulfuric acid environments).

- Nuclear/power plants (N08811 for creep resistance).
